Product name: Ultrasonic automatic frequency tracking welding machine, ultrasonic machine
Application scope:
Professionally used in small and large quantities of ABS, PE, PC, PS, PVC, PP, ABS and PC composites, acrylic and other plastic material products, automated welding production. Such as: welding processing of brand elevators, SD cards, CF cards and other products.
Uses and features:
1. Specializing in the automatic welding production of small and large quantities of ABS, PE, PCPS, PVC, PP, ABS and PC composites, acrylic and other plastic materials.
2. The precision divider device is driven by a motor for precise positioning.
3. Microcomputer touch screen and PLC programmable control system, easy to operate.
4. The output of Japan's original piezoelectric ceramic transducer is strong and stable, and the king-brand steel horn is durable.
The principle of ultrasonic welding: Ultrasonic welding uses a transistor function device to convert the current 50/60KHz electric frequency to 20KHz and 40KHz high-frequency electric energy, supplying the converter, and the ultrasonic transducer converts the electric energy into ultrasonic energy, that is, the frequency exceeds humans. The high-frequency machine vibration energy of ear hearing is transmitted to the plastic workpiece through the welding head, and the joint surface of the plastic product is violently rubbed and melted with tens of thousands of ultrasonic frequencies per second and a certain amplitude. After the vibration stops, it remains in the product. The short-term pressure on the welding molecules solidifies the welding molecules into one body. Generally, the welding time is less than 1 second, and the resulting welding strength is comparable to itself.
Technical parameters of automatic ultrasonic machine :
Product Details | technical parameter | Product Details | technical parameter |
machine type: | HS-2615 | frequency: | 15KHz |
Output Power: | 2600W | Drive mode: | PNEUMATIC |
voltage: | 220/380V*3P 50/60HZ | Welding head stroke: | 70MM |
Air pressure: | 0.6Mpa | Vibration system: | Auto Stimulating |
Output time: | 0.1-99s | Air compressor: | 1HP |
Machine size: | 400*200*650MM | weight: | 120KG |
(All specifications related to the machine can be customized according to customer requirements. Due to the need for improvement, there will be no notice for specification changes)
Equipment application case:
